Tea Tags & Tea Envelope Technical Specifications
Products
Sub Navigation
Standard outer envelope system
Machine Platform
Teepack
Model
PERFECTA 450 / 600 / 700
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 (Z) | 230 – 300 GSM | 0.28 – 0.40 | 70 × 80 / 75 × 90 | 60 – 90 GSM paper or laminate | 0.060 – 0.120 |
High-speed envelope integration
Machine Platform
Teepack
Model
CONSTANTA 100 / 200
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 / 28 × 28 | 230 – 300 GSM | 0.28 – 0.40 | 70 × 80 / 80 × 85 | 60 – 100 GSM paper / foil laminate | 0.070 – 0.140 |
Compact high-speed system
Machine Platform
IMA Group
Model
C23
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 20 × 56 / 20 × 50 | 220 – 280 GSM | 0.25 – 0.35 | 65 × 75 / 70 × 85 | 50 – 90 GSM | 0.060 – 0.120 |
Export envelope integration
Machine Platform
IMA Group
Model
C24 / C27 / C2000
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 20 × 56 | 220 – 280 GSM | 0.25 – 0.35 | 70 × 85 / 75 × 90 | 60 – 100 GSM | 0.070 – 0.130 |
Premium automation lines
Machine Platform
IMA Group
Model
C51 / C52
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 20 × 56 / 25 × 60 | 220 – 280 GSM | 0.25 – 0.35 | 75 × 90 / 80 × 95 | 60 – 100 GSM | 0.070 – 0.140 |
Flexible packaging system
Machine Platform
Acma / Tecnomeccanica
Model
T2 PRIMA
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 20 × 56 / 28 × 32 | 220 – 280 GSM | 0.25 – 0.38 | 70 × 80 / 75 × 90 | 60 – 90 GSM | 0.070 – 0.120 |
Premium eco / knotless systems
Machine Platform
Acma / Tecnomeccanica
Model
T4 MODULA
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 25.4 × 31.75 / 28 × 32 | 230 – 300 GSM | 0.28 – 0.40 | 75 × 90 / 80 × 95 | 70 – 100 GSM | 0.080 – 0.140 |
Ultra-high-speed systems (~500 bpm)
Machine Platform
Acma / GD
Model
T10 CONTINUA
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 / 20 × 56 | 230 – 300 GSM | 0.28 – 0.40 | 80 × 90 / 85 × 100 | 70 – 110 GSM | 0.080 – 0.150 |
Wide premium envelope branding
Machine Platform
Mai S.A.
Model
MAI 12 / 15
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 47 × 27 / 40 × 25 | 240 – 320 GSM | 0.30 – 0.45 | 80 × 90 / 85 × 95 | 70 – 120 GSM | 0.090 – 0.150 |
Luxury herbal tea segment
Machine Platform
Mai S.A.
Model
Pyramid Series
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| Pyramid | 250 – 320 GSM | 0.30 – 0.45 | 90 × 100 / pouch format | 80 – 120 GSM laminate | 0.100 – 0.160 |
Tight tolerance premium export
Machine Platform
FUSO International
Model
FP / FPG Series
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 / 20 × 24 | 230 – 300 GSM | 0.28 – 0.40 | 70 × 85 / 75 × 90 | 60 – 100 GSM | 0.070 – 0.130 |
Teepack-compatible envelope system
Machine Platform
Constanta
Model
100 / 200
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 / 28 × 28 | 230 – 300 GSM | 0.28 – 0.40 | 70 × 80 / 80 × 85 | 60 – 100 GSM | 0.070 – 0.140 |
High-end luxury packaging
Machine Platform
ECM
Model
EC Series
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 / custom | 240 – 320 GSM | 0.30 – 0.45 | 80 × 90 / premium custom | 80 – 120 GSM laminate | 0.100 – 0.160 |
Herbal / flexible packaging
Machine Platform
Xiamen Sengong
Model
DXDCH / Pyramid
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 20 × 24 / custom | 220 – 300 GSM | 0.25 – 0.40 | 80 × 90 / pouch / pyramid pack | 60 – 120 GSM | 0.070 – 0.160 |
Economical market systems
Machine Platform
Ruian Snda Machinery
Model
DXDC series
| Tea Tag Size (mm) | Tea Tag GSM | Tea Tag Thickness (mm) | Tea Envelope Size (mm) | Envelope GSM / Material | Envelope Thickness (mm) |
|---|---|---|---|---|---|
| 28 × 32 / 25 × 28 | 220 – 280 GSM | 0.25 – 0.35 | 70 × 80 / 75 × 85 | 50 – 90 GSM | 0.060 – 0.120 |
